    5m RGB COB LED Strip Light - COB Series Color-Changing LED Tape Light - 12V/24V - IP20

      (2 Reviews) | Write a review
    SKU: COB-IP20-RGB-5m

    Please Choose:



    Discontinued
    Starting at: $126.95
    • 30 Days Return
    • 5 Years Warranty
    Add to Wishlist
    Deliver between Thu,Nov,21 and Wed,Nov,27. order with 2days,9hrs and 31 min.

    COB Series COB LED Strip Light creates a smooth, seamless Color Changing color light. Chip-on-board technology has a higher density of LEDs, for a more intense, uniform light that reduces heat buildup. Superior design will not show visible dots or hot spots, making it ideal for reflective surfaces such as granite countertops and tile floors. With no need for additional diffusers, the low profile strip can illuminate narrow applications such as backlighting or displays. Improved flexibility can wrap light along edges and curved surfaces.

    Product Details:

    1. Strip width: 10mm
    2. 3M™ adhesive backing
    3. Flexible COB design for highly adaptable mounting
    4. 2.46 in. (62.5 mm) segment length
    5. 12 VDC or 24 VDC input voltage
    6. 50 W total (3.05 W/ft)
    7. 30,000 hour lifetime (L70)
    8. 16.4 ft (5 m) max run
    9. 0-100% dimmable
    10. Connection: pigtail
    11. 160° beam angle
    12. UL Listed
    13. IP20 Rated for dry conditions
    14. 5-year warranty

    Warranties & Certifications

    Should you select 12 Volt (12v) or 24 Volt (24v)?
    Depends on your application. The main difference between the two is the fact that the 24v strips can be ran for longer distances than the 12v strips can due to Voltage Drop. Voltage drop is the gradual decrease in voltage along a circuit. If your project requires a very long run of LEDs, we would recommend the 24v strips. However, there are also many projects that 12v is required (automotive or marine applications). Please feel free to live chat with us, or email us with questions.
    Before noticing any unwanted color variations or dimming at the end of your run of lights, it is recommended that you run no more than 32' in series when using 12v or 48' in series when using 24v.

    Application & Use
    SmartBrightLEDs White Series LED strip lights are installed in a wide variety of applications including:
    TV backlighting, Linear lighting, Cove lighting, Display / jewelry case lighting, Bar and restaurant accent lighting, Above cabinet lighting, Under counter lighting, Hotel lobbies, Cove lighting


    TECHNICAL DETAILS

    Voltage 12V DC/ 24V DC
    LED Color RGB
    LED Beam Angle 180 degree
    LED Type COB (flexible)
    LED Density 156 LEDs/ft.
    LED Quantity 2560 LEDs
    LEDs per Segment 32
    Max Run Up to 16.4ft (5m)
    Power Consumption 50 Watts
    Strip Width 10mm (0.39in)
    Rated Lifespan 50,000 hours
    Length 16.4ft (5m)
    Dimmable Yes (requires Trulux controller)
    Wattage per Foot 3.1 W/ft (10.2 W/m)
    Minimum Cut Length 62.5mm (2.46in)
    Protection Rating IP20
    Environmental Rating Non-Weatherproof
    Wire Length 508mm (20in)
    Ambient Operating Temperature -20~+40 °C (-4~+104 °F)
    Certifications/Compliance CE, RoHS Compliant, UL Listed

    **All specifications are subject to change without notice.

    Download COB Series Single Color,CCT and RGB Specification Sheet


    Incorrect Use:

    Packaing Diagram

    Use of environmental conditions
    1). LED strips installation must be operated by professionals.
    2). For avoiding LED get vulcanized, LED strip should be installed in the environment where does not has oil and corrosive substances. Such as these substances which contain Sulphur、Bromine、Iodine and Chlorine. Some other chemical elements which will cause Aromatic hydrocarbons releasing(such as: methylbenzene、xylene、methyl acetoacetate Ethyl acetate etc.).The environment in which includes strong acid and strong base.
    3). For cutting LED strip operation, it is necessary to use the standard accessories provided by smartbrightLEDs (e.g. DC wire, end-cap, front-cap, adhesive, etc.), and according to the correct cutting and connecting method for the installation.
    4). LED strip cannot be installed in some areas where water hazard might be formed, such as the surface of pits and ditches. And similar places in which rain and water may be accumulated easily.
    5). Please do not strongly pull、crash the LED strips during  installation  process. And avoid squeezing and scratching LED strips with sharp objects.
    6). During the warranty period, only defective products are acceptable to be replaced by the factory.  Factory is not responsible for other expenses because of replacement,such as transportation fee, installation fee, etc.



                                                                                                                                                 Cautions
    1. In order to guarantee the LED life and the use environment, cannot make any force when the product lighting use to pull the power cables, forbids to collide, in order to avoid damages LED.
    2. For better lighting effect of the product, each 5 meters strip must connect the main power source.
    3. Must guarantee that each power source (GND) must be connected.
    4. Should not be curving in the diameter 60mm following radian, please do not rebate, in order to avoid damage lamp bead or break.
    5. Please follow the user manual for installation.
    6. Please note the careful operation, in the power source connection's situation, will touch the alternating current supply end possibly to cause your safety.
    7. In the actual application, the power source should retain 20% remainders, guaranteed that the sufficiency the voltage lightens LED.
    8. Installs as far as possible the product in the appropriate environment.
    9. Pays attention to the power cable in the installment process positive and negative extremely, please do not wrong, power source and product voltage to be whether correct, in order to avoid creates the product the damage.

    ** If you do not follow the above "Cautions" to operate and result in damaging the product, the factory will not accept maintenance and return.
