Rigid RGB LED Light Bar w/ High Power 3-Chip SMD LEDs
Rigid linear RGB LED light bars are an extremely versatile solution for a variety of lighting needs, such as cabinet lighting, under-cabinet lighting, cove lighting, task lighting, bookshelf lighting, showcase lighting, cupboard lighting, or other indoor applications where space is limited. This dimmable 1-7/8' light bar uses 5050 SMD RGB LEDs to emit colorful illumination. Use a compatible RGB controller for color selection and color-changing modes. The bar has a separate RGB power input and a common anode female socket. Easily join up to 10 fixtures with compatible interconnect cables (sold separately). Wire must run back to the power source every 10 meters to avoid voltage drop. The non-weatherproof light fixtures have 12 VDC operation and can be cut into 3-LED segments.
Warranties & Certifications
Application & Use
LED Backlights, Accent Lighting, Off Grid Lighting, Coves, Under-Cabinets, Display Case, Trade Shows
Specifications
Beam Angle: 180 degree
Comparable Wattage: 45-50 Watt Incandescent
Connection Type: RLBN Female
Current Draw: 0.4A (400mA)
Current Draw per Foot: 247mA
Dimmable: Yes
IP Rating: Non-Weatherproof
LED Color: RGB
LED Lifetime: 40000 Hours
LED Type: 5050 SMD
LEDs per Segment: 3
Linkable: Yes
Lumen Per Foot: 244 lm/ft (800 lm/m)
MCD Per LED: 1200
MCD per Foot: 21946 mcd/ft
Max Run: 10
Max Run in Feet: 18.8ft
Millicandela: 36000mcd
Number of LEDs in Unit: 30 LEDs
Operating Voltage Range: 12 VDC
Standards And Certifications: ISA Approved, RoHS Compliant
Strip Width: 8mm (0.31in)
Total Length: 23in (1.88ft)
Total Power Consumption: 4.9 Watts
Wattage: 5 Watts
Wattage per Foot: 3 Watts
Wavelength: 470 nm, 525 nm, 626 nm
Package Weight: 0.9oz (0.03kg)
Package Dimensions: 22.5" (57cm) x 0.22" (1cm) x 0.22" (1cm)
All specifications are subject to change without notice.
