45W LED Retrofit Kits for 125W Metal Halide Fixtures 6,480Lm Parking Lot Lighting Retrofit
45W LED retrofit kit, 144LM/W high efficiency, ETL cETL DLC CE RoHS certified. Rotatable angle and E40 E39 E27 E26 base allows the retrofit kit to adapt to a wide range of luminaires. Widely used in replacing HID, MH bulbs in Shoebox, Wall pack, Canopy, High Bay, Cobra head Street fixtures.
Feature
- 5 years warranty.
- 0-10V Dimmable Optional.
- Various beam angle of 120 degree.
- Original Lumileds 3030 LEDs which is up to 144Lm/W.
- Arm adjustable with any beam angle.
- With a big Sunon fan(60,000hours).
- Body Temperature:<55 oC @Ta=25 oC
- With the most excellent quality meanwell driver.
- Available with both 100-300VAC & 347VAC & 480VAC.
- Using aluminum fin heat sink which heat transfer faster than die cast.
- Tiny package and lighter,lower freight cost,more competitive in the market.
- Avaialble for low bay fixture,street pole,canopy,parking lot shoebox,wall pack,high bay fixtures etc.
- ETL DLC CE Lm79 Lm80.
Warranties & Certifications
Specifications
Watt: 45W
Lumen: 6,480 Lumen
Efficiency: 144Lm/W±3%
Chip Brand: Lumileds 3030
Input Volt: 100-277VAC
Driver: Sosen Driver SS-50VA-56
CCT: 3000-6000K
Size: 315*149.6mm
Weight: 0.8kg
Fan: Without
Base: E40/ E39(mogul)/ E26/ E27(Medium)
Equivalent: 75W to 105W metal halide / HID lamp Equivalent
Power Factor: >0.95
Beam Angle: 120 degrees
IP Rating: IP60
CRI: >80
Working Tempe / Humidity: -45 to + 50 Deg C / @Ta=25 Deg C
Warranty: 5 year Warranty
Rated Lifespan: 50,000+ hours
Certified: ETL DLC CE Lm79 Lm80
View Dimensional Drawings
1.Sunon fan ; 2.Hexagon heat sink; 3.E40 to E27; 4. Aluminum heat sink; 5.Philips SMD 3030;
1.Using aluminum fin heat sink which heat transfer faster than die cast.Tiny packageand lighter,lower freight cost,morecompetitive in the market. Lamp :0.8kg;
2.Using AL1050 aluminum fin heat sink.Can be used in a sealed environment.Thermostatthermal protector;
3.Module Rotatable 360 degree;
