Since 2010, we have started the lighting business and have served thousands of customers. We are a professional manufacturer and supplier of LED Stadium Area Flood lights. Our products are sold all over the world and are well received by customers.Compared with traditional stadium lights, Dragonfly max LED stadium lights have higher efficiency, higher uniformity and lighting quality, and longer service life. Replace your old lamps, you can get more than 75% off monthly lighting costs! contact us whenever necessary!

Warranties & Certifications

Features
More convenien - The power supply can be installed separately from the lamp, which reduces the load bearing on the top of the pole and makes subsequent maintenance more convenient;
High uniformity - The lamp module can be flexibly rotated, and different lenses can be used to achieve the best uniformity of illumination of the venue;
High Efficiency - Using the latest LED lighting technology, the light efficiency reaches 200Lm/W, replacing your existing HPS/MH you can save 75% of electricity bills every month;
Quick install - Adopt fast male and female connector to complete the installation quickly and save manpower;
Certification - Passed the ETL TUV CE CB SAA RoHS LM79 LM80 TM21 IK10 Salt Spray test approved certification;

Specifications
Watt:    1200W
Lumen:    240,000Lumen
Efficiency:    200Lm/W±3%
Driver:    Meanwell Driver 6pcs ELG-240-48A
Input Volt:    100-277VAC
Chip Brand:    Lumileds/ Osram 5050
CCT:    4000K 5000K
Weight:    36.5KG / 80.4 lbs
Size:    L818.5 x W962x H785mm L32.3" X W37.9" X H31"
Beam Angle:    20/ 40/ 60 degree
Certification:    ETL TUV CE CB SAA RoHS LM79 LM80 TM21 IK10 Salt Spray test approved

View Dimensional Drawings

1.The fixed buckle of the module is made of stainless steel and the left and right direction of the module can be adjusted by ±45 degree;
2.Knob fixing which is for tool-free adjustment of module angle ±45 degree;
3.Each Module of comes with Waterproof Breathable Pressure Relief Vent Plug;

Applications
Applied in large sports field lighting, golf and tennis court,racetrack,
badminton, roads, football, basketball, tower lights, etc. Can also be applied in large square, airport, commercial building, construction engineering, farm, amusement parks, parking lots, harbor, industrial buildings, and other special lighting environment.
