    Sunricher DALI to 0-10V Converter

      (10 Reviews) | Write a review
    SKU: SBL-SR230301VPWM
    Discontinued
    Starting at: $146.95
    • 30 Days Return
    • 5 Years Warranty
    Add to Wishlist
    Deliver between Thu,Nov,21 and Wed,Nov,27. order with 2days,9hrs and 31 min.

    This high quality DALI to 0-10V / PWM converter is from the Sunricher range. It is designed to integrate a 0-10v interface into a DALI controlled system.
    The PMW converter is the perfect installation for domestic and commercial markets. It can be used in a range of spaces such as hotels, offices and retail outlets. The digital interface enables the DALI address to be easily entered into the unit making control over your lighting easy.
    The LED light receiver is perfect for dimming and switching on or off single colour LED lighting. It can be used for a range of products such as single colour LED Tape / LED strip lights or Neon flex.
    The LED receiver receives the DALI signal via DALI input connectors. The output from the PWM controller is 2 channels of 0-10v signals. This can then be connected to an existing 0-10v dimmer driver.
    The receiver unit features DALI output connection to link multiple units together. One DALI address will control both 0-10v output channels together.
    The receiver requires an input voltage of 100v - 140v AC with the same output.
    This is a perfect solution to extending your DALI network where 0-10v LED control is required.


    Technical Specification
    Product Code:    SR230301VPWM
    Product Packed:    Gift box
    Product Type:    0-10v Dimmer
    Colour:    White
    IP Rating:    IP20 Non-Waterproof
    Guarantee Period:    5 Years
    Input Voltage:    100v - 240v AC
    Output Voltage:    100v - 240v AC
    Connectivity:    DALI protocols
    PCB Weight:    Not Applicable
    Size    180 x 73.6 x 38mm
    CRI Rating (greater than):    CRI >80
    Dimmable:    Yes
    LED Type:    Not Applicable
    Average LED life Hrs:    30,000
    Colour Temperature Variation:    IP20 No
    Power Factor >:    Not Applicable
    Continuous Operation:    Not suitable for 24/7 continuous use
    Relative Humidity:    8% to 80%
    Operating Temp:    0-40°C
