Sunricher Professional Constant Voltage 12V 200W DMX Driver with RDM
This high quality, professional 200w, 4 channel DMX LED Driver from our range of Sunricher control systems is a UL, ENEC and TUV approved product. This driver features RDM bi-directional communications (when used with an RDM enabled DMX controller).
With a 12v constant voltage output and a 100v to 240v AC universal input, this DMX driver has many professional features including:
Adjustable PWM frequency (500Hz to 30kHz)
Adjustable PWM output resolution (8bit and 16bit)
Adjustable Gamma-Ray dimming curve from 0.1 to 9.9 with logarithmic or linear dimming options.
The unit can be set to 1, 2, 3 or 4 channel modes and it has a power factor of over 0.9 which is greater than 90%. the driver offers smooth dimming with no flickering and when dimming the driver is silent with no audible buzz.
This DMX Driver with RDM features is compatible with our range of LED tapes and other LED lights.
This DMX driver is ideal for use in TV studios with professional filming equipment as there is no banding or flickering when dimming.
Technical Specification
Product Code: SRPC210812200CVF
Product Packed: Gift box
Manufacturer: LED Technologies
Product Type: DMX 512 Driver
Colour: Brushed Aluminium
IP Rating: IP20 Non-Waterproof
Guarantee Period: 5 Years
Wattage: 200w
Current: Max. 8.3A/ch
Input Voltage: 100v - 240v AC
Output Voltage: 12v DC
Connectivity : DMX 512 protocols
Size: 330 x 79 x 39mm
Dimmable: Yes
Average LED life Hrs: 30,000
Colour Temperature Variation: IP20 No
Power Factor >: 0.98
Wireless Range: Up to 30 metres
Continuous Operation: Not suitable for 24/7 continuous use
Voltage Type: Constant Voltage
Adjustable Dimming Curve & Gamma Value: Yes
Adjustable Bit Rate: Yes
Adjustable PWM: Yes
Relative Humidity: 8% to 80%
RDM: Yes
Operating Temp: -20 to +45
