This slim, two-channel RF to Phase-Cut & Push AC Dimmer RF receiver is available from our Sunricher range of professional lighting control products. This RF LED receiver is an installation-grade product suitable for use in domestic and commercial environments such as hotels, restaurants and retail outlets.
The LED light receiver/switch can be paired to a compatible Sunricher radio frequency (RF) remote controller and will then power on or off your mains-powered devices. This switch also allows you to dim your single-colour LED strip lights and other LED lighting units.
The LED remote receiver also supports both resistive and capacitive loads and is both TRIAC and MOSFET dimmable. It also features an innovative minimum brightness function which is user settable. The switch is a single channel unit with a maximum load of 1.5A, it also incorporates optional Push Dimming terminals.
This RF receiver/switch can be used to control your LED Tape in a single zone via RF signal to an LED controller. This product can also be used in a multiple zone set-up with multiple receivers.
Browse our range of LED tape that can be controlled with this Sunricher RF receiver. Sunricher products also include a range of single colour, RGB & RGBW colour-changing LED RF receivers. This receiver can be implemented into your home automation system for control through smart home hubs.

Technical Specification
Product Code:    SR1009SACHP
Product Packed:    Gift box
Manufacturer:    LED Technologies
Product Type:    Controller / Receiver
Colour:    White
IP Rating:    IP20 Non-Waterproof
Guarantee Period:    5 Years
Input Voltage:    100v - 240v AC
Output Voltage:    100v - 240v AC
Connectivity:    RF
PCB Weight:    Not Applicable
Size:    45.5 x 45 x 20.3mm
CRI Rating (greater than):    CRI >80
Dimmable:    Yes
LED Type:    Not Applicable
Average LED life Hrs:    30,000
Colour Temperature Variation:    IP20 No
Power Factor >:    Not Applicable
Wireless Range:    Up to 20 metres
Continuous Operation:    Not suitable for 24/7 continuous use
Voltage Type:    Mains Voltage
Relative Humidity:    8% to 80%
Operation Frequency:    869.5 /434 / 916.5MHz
Operating Temp:    0-40°C
