This amber LED is designed for models, sign lighting, indicator lights, and other small projects. It has an output of 9,000mcd and a dominant wavelength of 605nm. The T1 through-hole 3mm LED has a clear lens and emits a 15° beam of illumination. It has a typical forward voltage of 2.0V at 20mA and a peak forward current of 100mA. Use of a resistor or other current-limiting device is crucial to prevent premature LED failure. Component LEDs are sensitive electronic devices and require some knowledge of electronic circuits to operate. Price listed is per unit; however, bulk discounts are available and are automatically applied to your order.

Dimensional Drawings

TECHNICAL DETAILS
Continuous Forward Current:    20 mA
Forward Voltage:    2.0V
LED Color:    Amber
LED Package:    3 mm (T-1)
Lens:    Clear
Lumen:    0.5 Lumen
Maximum Forward Voltage:    2.4V
Millicandela:    9000mcd
Operating Temperature:    -40~+85 °C (-40~+185 °F)
Peak Forward Current:    100mA
Power Dissipation:    60mW
Reverse Current:    10µA
Reverse Voltage:    5V
Storage Temperature:    -40~+85 °C
Total Power Consumption:    0.04 Watts
Tube Diameter:    T-1
Viewing Angle:    15 degree
Wavelength:    605 nm
Package Weight: 0.01oz (0kg)
Package Dimensions: 0.24" (1cm) x 0.16" (0cm) x 0.16" (0cm)

Applications / Uses
Industrial controls, Medical equipment, Communications equipment, Test and measurement, Security electronics.
